Description
| Specifications | |
|---|---|
| Model | C-4401 |
| Condition | Surplus New | General |
| Thickness | 1/16" |
| Material | Aramid Fiber/NBR |
| Diameter | 23 " |
| Outside Diameter (Metric) | 660 mm |
| # of Holes | 14 |
| Other Specifications |
|---|
|
Creep relaxation ASTM F38B (1/32"): 20 %
Sealability ASTM F37A (1/32"): < 0.25 ml/hr
Gas Permeability DIN 3535/6: < 0.5 ml/min
Compressibility ASTM F36J: 7 - 14 %
Recovery ASTM F36J: 50 % minimum
KLINGER Hot Compression Test
Thickness Decrease 73°F (23°C): 14 % initial
Thickness Decrease 572°F (23°C): 17 % additional
Weight increase ASTM F146 after immersion in
Fuel B, 5h/73°F (23°C): 10 % maximum
Thickness Increase ASTM F146 after immersion in
ASTM Oil IRM 901, 5h/300°F (149°C): 0 - 5 %
ASTM Oil IRM 903, 5h/300°F (149°C): 0 - 5 %
ASTM Fuel A, 5h/73°F (23°C): 0 - 5 %
ASTM Fuel B, 5h/73°F (23°C): 0 - 10 %
Dielectric Strength ASTM D149-95a: 14 kV/mm
Density ASTM F1315: 112 lb/ft ³ (1.8 g/cc ³)
Leachable Chloride Content FSA Method: 100 ppm
ASTM F104 Line Call Out: F712121B3E12K6M5
Color: Green
|
