Description
| Specifications | |
|---|---|
| Model | HRT210 |
| S/N: | 233489 |
| Condition | Used |
| Other Specifications |
|---|
Platter Platter Diameter: 8.30 in. // 210 mm Max Weight on Platter: 170 lb // 77.1 kg Max Weight on Platter (unsupported): 85 lb // 38.6 kg Number of Std T-Slots: 6 @ 60 deg. Spindle Max Speed: 100 °/sec. // 100 °/sec Torque (Continuous): 210 ft-lbf, // 285 Nm Runout Max: 0.0005 in. // 0.013 mm Center Height: 6.000 in. // 152.40 mm Backlash: 30 arc-sec // 30 arc-sec Brake Torque @ 100 psi/6.9 bar: 200 ft-lbf. // 271 Nm Gear Ratio: 90:1. // 90:1 Timing: 2:1 Indexing Accuracy: 15 arc-sec. // 15 arc-sec Repeatability: 10 arc-sec // 10 arc-sec Resolution: 0.001 ° // 0.001 ° Worm Gear Dia: 6.3 in // 160 mm Max Rotation/Step (with rotary control): 999.999 ° // 999.999 ° Air Requirements Air Pressure Max: 150 psi // 10.3 bar |
